Losoeo Lens

Sensor 1/2.9" F1.60 6Glass Camera Fisheye Lens for Car Recorder HD DVR Big F/NO 1.6

[复制链接]
发表于 2019-12-15 13:04:51 | 显示全部楼层 |阅读模式
Lens
Image:
Model: LS2079A6
classification: Sport Camera Lens Drone Lens Car Camera Lens Rear View Camera Lens CCTV Lens
Sensor Size: 1/2.9 1/3
Optical FOV(H): 95 100
F/NO: 1.6
Focal Length: 2.9
Total Length: 23 24
[backcolor=rgba(0, 0, 0, 0.05)]
1. Fisheye lens
2. Big F/NO 1.6
3. Factory direct shipment
4. Free sample

Sensor 1/2.9" F1.60  6Glass Camera Fisheye Lens for Car Recorder HD DVR
Product Specification
Product ModelLS2079A6
Sensor TypeJX-H65
Focal Length(mm)2.9
Total Length(mm)23.92
F/NO1.6
Max Image Circle4.38
Optical FOV(D)128°
Optical FOV(H)98°
Optical FOV(V)71°
TV Distrotion<19%
Relative Illumination>88%
Chief Ray Angle<10°
Structure6 Glass+1 IR
Operation Temperature-30°C~+70°C
Storage Temperature-40°C~+85°C
