Sony索尼IMX图像传感器芯片参数规格书

型号	参数	备注
IMX335LQN-C	IMX335芯片参数： CMOS活动像素类型点 内置定时调整电路、H/V驱动和串行通信电路 输入频率：6至27兆赫/37.125兆赫/74.25兆赫 推荐记录像素数：2592(H)×1944(V)左右。5.04m像素 4 i. U8 h1 q8 |( l  H% a读出模式：所有像素扫描模式；水平/垂直2/2线组合模式；窗口裁剪模式；垂直/水平方向-正常/倒置读出模式 读出率：全像素扫描模式2592(H)×1944(V)AD 10位的最大帧速率：60帧/s 宽动态范围(WDR)功能：多次曝光WDR；数字重叠WDR 变速快门功能(分辨率1H单位) ! y; s, s" P% z& ]10位/12位A/D转换器 CDS/PGA功能0dB至TBDdB(步长0.3dB)支持I/O CSI-2串行数据输出（2个通道/4通道，RAW10/RAW12输出） ! K/ ^2 G1 b% X) n0 _1 h推荐的出射光瞳距离：-30mm至-1
IMX386	IMX386是一个对角线6.294毫米(1/2.86型)12兆像素CMOS有源像素型叠加型图像传感器与方形像素阵列。采用Exmor RS技术实现高速图像采集。
IMX415	The IMX415 from Sony Corporation is type 1/2.8 4K-resolution stacked CMOS image sensor. The ample pixel size of 1.45 square µm coupled with the latest pixel technology for low-noise capabilities, improves the low-light performance, making this sensor ideal for high-end 4K security cameras. This image sensor is ideal for security cameras in a variety of monitoring applications such as anti-theft, disaster alert, and traffic monitoring systems or commercial complexes.
IMX214	Place of Origin 8 M; X9 \, ?' o1 B5 a) w( JGuangdong, China ! j" E, V* r$ L/ F # ?! O4 a! w  b2 `* rModel Number + ?4 b3 B1 Q; V2 w  S, T7 \! I. C# K214-130V1 1 [+ J5 o/ Z/ V* S7 }Sensor 0 i2 u+ ~4 P: j, [3 f. S1/3'' SONY IMX214 / [: c; f; G) w/ e! z ) n! }+ |2 d% E) M: b Lens SENSOR CMOS 0 q9 y: B8 {1 X& K( ^' I5 k; r* V $ G4 H% W7 w9 S. CModule Size & H, P. W: {" B2 Y6 z6 E28.55*10.8*5.7mm / OEM ! h+ e) a, l6 E7 ]) ~! S
! \8 z' e. Z+ W! LIMX179QQH5-C	The IMX179 is a diagonal 5.7 mm (Type 1/3.2) CMOS active pixel type image sensor with a square pixel array and 8.08M effective pixels. This chip operates with three power supplies, analogue 2.7 V, digital 1.2 V, and IF 1.8 V, and ! ^9 E5 ~- g( thas low power consumption. High sensitivity, low dark current, and no smear are achieved through the adoption of R, G, and B primary color pigment mosaic filters. This chip features an electronic shutter with variable charge-storage time. In addition, this product is designed for use in cellular phone and tablet PC. When using this for another application, ( h2 I  [  _) HSony does not guarantee the quality and reliability of product. Therefore, don’t use this for applications other than cellular phone and tablet PC. Consult your Sony sales representative if you have any questions.	◆CMOS active pixel type dots ◆2-wire serial communication circuit on chip ◆CSI2 serial data output ◆Timing generator, H and V driver circuits on chip ◆CDS/PGA on chip 1 v* ]" |7 ^# P◆10-bit A/D converter on chip + w% d  j' B% W# S$ L% b+ Q' o◆Automatic optical black (OB) clamp circuit on chip ) M8 M$ q- v2 r8 `◆PLL on chip (rectangular wave/sine wave) + _* q0 ]* S- h$ S5 C1 F4 G◆High sensitivity, low dark current, no smear 7 ]$ x" ~/ C/ n% I8 [# e# Z◆Excellent anti-blooming characteristics , v6 z% N* D. [* Z. V◆Variable-speed shutter function (1H units) ◆R, G, B primary color pigment mosaic filters on chip ◆Max. 30 frame/s in all-pixel scan mode ! A0 J4 t& ~9 U◆Pixel rate: >260 MHz (>30 frame/s at All-pixel mode) / W0 t" V7 J( o& n
IMX377	DESCRIPTION 6 o& D* ]& z& C0 |! VDiagonal 7.81 mm (Type 1/2.3) CMOS Image Sensor with Square Pixel for Color Cameras 2 B% ]& }" }2 ~- ?The IMX377CQT is a diagonal 7.81 mm (Type 1/2.3) CMOS image sensor with a color square pixel array andapproximately 12.35 M effective pixels. 12-bit digital output makes it possible to output the signals of approximately12.35 M effective pixels with high definition for shooting still pictures. It also operates with three power supplyvoltages : analog 2.8 V, digital 1.2 V, and 1.8 V for I/O interface and achieves low power consumption. Furthermore, itrealizes 12-bit digital output for shooting high-speed and high-definition moving pictures by horizontal and verticaladdition and subsampling. Realizing high-sensitivity, low dark current, this sensor also has an electronic shutterfunction with variable integration time.In addition, this product is designed for use in consumer use digital still camera and consumer use camcorder. Whenusing this for another application, Sony Semiconductor Solutions Corporation does not guarantee the quality andreliability of product. Therefore, don't use this for applications other than consumer use digital still camera andconsumer use camcorder.In addition, individual specification change cannot be supported because this is a standard product.- CMOS active pixel type pixels- Input clock frequency 6 to 27 MHz- MIP! Specifications (CSI-2 high-speed serial interface)-All-pixel scan modeVarious readout modes (*)- High-sensitivity, low dark current, no smear, excellent anti-blooming characteristics- Vertical and horizontal arbitrary cropping function- Variable-speed shutter function (minimum unit 1 horizontal period)- Low power consumption
